Electrical Transformer Radiators

Name: Electrical Transformer Radiators
Brand: THERMOCOOL ENGINEERING PVT LTD
Price: 5000-100000 INR
Availability: InStock

Price 5000-100000 INR/ Piece

Get a Price/Quote

MOQ : 100 Pieces

Electrical Transformer Radiators Specification

Material
Mild Steel or Stainless Steel

Water Content
12-15 Litre per fin (typical)

Central Distance
500 mm, 1000 mm, 1200 mm, 1500 mm (customizable)

Working Pressure
1.5 Kg/cm² (150 KPa/0.15 MPa)

Rough Weight
28-45 Kg/fin (varies as per size)

Thermal Pressure
85°C to 115°C temperature range

Dimension (L*W*H)
As per specification (e.g., Width: 310 mm to 520 mm, Length: up to 2000 mm, Height: as per customer requirement)

Advantage
High heat dissipation, Easy installation, Leak-proof design, Corrosion-resistant coating

Customization
Available for dimensions and fitting locations

Design Standards
IS:3347, IEC 60076, or as per customer specification

Test Pressure
2.5 Kg/cm2 for 30 minutes (hydrostatic)

Surface Finish
Epoxy based anti-corrosive paint or hot dip galvanized

Applications
Power/Distribution Transformers, Industrial Transformers

Connection Type
Flanged and welded or detachable connections

Number of Fins
Based on transformer rating and heat dissipation requirements

Packaging
Bubble-wrap sheet & wooden crate packing

Fin Type
Elliptical or Corrugated, as per IS-3347/IS-4257 standards

Electrical Transformer Radiators Trade Information

Minimum Order Quantity
100 Pieces

FOB Port
kolkata

Supply Ability
100 Pieces Per Month

Delivery Time
15 Days

Sample Available
No

Packaging Details
Standard

Main Export Market(s)
Australia, Middle East, Africa, Asia

Main Domestic Market
All India

Certifications
iso 9001:2015

About Electrical Transformer Radiators

Electrical Transformer Radiators :-

Product Details:

Minimum Order Quantity	100 Piece
Certification	TUV Stamp
Type	Customised
Tube Type	Seamed
Coolant Used	Synthetic Liquid

The Electrical Transformer Radiators are highly efficient in nature. We are providing this Electrical Transformer Radiators in various dimensions and specifications. Electrical Transformer Radiators is extensively used in industrial applications. Moreover, we deliver this Electrical Transformer Radiators to various places in speculative time limits.

Features:

Quality assured
Easy to use
Longer functional life

Superior Heat Dissipation and Reliability

These transformer radiators are designed with elliptical or corrugated fins to maximize heat transfer, supporting stable transformer operation over a range of temperatures. Their customization options and strict compliance with IS-3347 and IEC 60076 standards ensure they meet the precise performance requirements of various applications, from distribution to industrial transformers.

Robust Construction and Easy Installation

Manufactured from premium-grade mild steel or stainless steel, our radiators are coated with epoxy-based anti-corrosive paint or hot dip galvanized for extended lifespan. The choice of flanged, welded, or detachable connections ensures straightforward and secure installation. Each unit undergoes rigorous testing, including a hydrostatic pressure check, to guarantee a leak-proof and reliable solution.

FAQs of Electrical Transformer Radiators:

Q: How are transformer radiators with elliptical or corrugated fins selected for specific applications?

A: The selection of radiator fin type, dimensions, and number of fins is determined by the transformers rating and heat dissipation requirements. Customization ensures optimal performance, supporting efficient cooling in both power and industrial transformer installations.

Q: What standards do these electrical transformer radiators comply with?

A: Our radiators adhere to IS:3347, IS-4257, and IEC 60076, or can be manufactured according to customer specifications. Rigorous quality control ensures compliance with these internationally recognized standards.

Q: When should the transformer radiator be tested for pressure and what is the process?

A: The radiators undergo a hydrostatic test at 2.5 Kg/cm for 30 minutes during manufacturing. This process verifies leak-proof construction and ensures each unit can withstand operational working pressures of up to 1.5 Kg/cm.

Q: Where can these transformer radiators be installed and used?

A: These radiators are suitable for installation in power transformers, distribution transformers, and various types of industrial transformers, serving electrical substations, utilities, and industrial facilities requiring robust heat dissipation modules.

Q: What benefits do epoxy-based and hot dip galvanized finishes provide?

A: Epoxy-based anti-corrosive paint and hot dip galvanized coatings protect the radiator from environmental factors, extending its lifespan and minimizing maintenance. This ensures long-term reliability in demanding conditions.

Q: How does customization enhance the application of these radiators?

A: Customization allows for tailored dimensions, central distance, water content per fin, and fitting locations, ensuring seamless integration and maximum efficiency for a variety of transformer designs and installation spaces.
